R 115,000.00
Basic Info
-
Work area (3 axis):36cm(X) * 24cm(Y) * 14cm(Z) / 14.2in * 9.4in * 5.5in
-
Work area (4 axis):9.2cm(Diameter) * 24cm(Length) / 3.6in * 9.4in
-
Gantry clearance:12cm / 4.7in
-
Max height (Lid open):84cm / 33in
-
Footprint:22.8in * 20.5in * 21.3in
-
Weight:50kg / 110lbs (approx)
Spindle
-
Power:200 watt
-
Speed:0 - 15000 RPM with closed-loop control
-
Collet:Custom collet with 1/8in integrated (optional: 1/4in, 6mm, 4mm)
-
Tool library size:6
-
Cooling:Air-cooled controlled by temperature monitor
Motion
-
Drive system:Ball screws with linear rails
-
Max traverse:600cm / 236in per minute
-
Motors:Servo motors for X/Y/Z axis, Nema17 stepper motor for A axis
Precision
-
Spindle runout:Less than 0.01mm / 0.0003in
-
Motor resolution:0.01 mm/ 0.0003in
Dust Control
-
Dust control:Integrated dust collection system
-
Dust tank volume:0.8 liter
Laser Engraver
-
Laser power:2.5 Watt
-
Laser Type:445nm semiconductor diode laser
-
Cooling:Air-cooled
Power
-
Power:100-120VAC / 200-240VAC @ 50/60Hz
Materials
-
Wood:Hardwoods, softwoods, MDF, plywoods, etc.
-
Plastic:Foam, PVC, ABS, Acrylic, PC, HDPE, etc.
-
Composite materials:Carbon fiber, FR4, etc.
-
Non-Ferrous metals:Aluminum, brass, copper, etc.
-
Laser engrave materials:Wood, plastic, fabric, leather, cardboard, etc.
Software
-
Controller:Dedicated software supports CARVERA functions
-
Controller connectivity:USB / WIFI
-
Controller OS:iOS, Andriod, Mac OS, Windows, Linux, etc.
-
Dedicated CAM software:Makera CAM
-
Compatible CAD/CAM software:Fusion360, SolidWorks, AutoCad, VCarve Pro, Aspire, Illustrator, etc.
