R 27,000.00
| Dimensions | |
| Work Area | 200mm(X) * 200mm(Y) * 100mm(Z) / 7.9in * 7.9in * 3.9in |
| 4th Axis Work Area (optional) | 80mm(Diameter) * 150mm(Length) / 3.1in * 5.9in |
| Gantry Clearance | 115mm / 4.5in |
| Max Height (Lid open) | 84cm / 33in |
| Footprint | 350mm(Width) * 470mm(Depth) * 450mm(Height) / 13.8in * 18.5in * 17.7in |
| Weight | 17kg |
| Spindle | |
| Power | 150 Watt |
| Speed | 0 - 13000 RPM with closed-loop control |
| Collet | Custom collet with ⅛in integrated (optional: ¼in, 6mm, 4mm) |
| Tool Change Method | Quick tool changer |
| Cooling | Built-in air cooling |
| Motion System | |
| Motor | NEMA 17 stepper motor |
| Drive Method | Linear rails + Acme lead screw |
| 4th Axis Drive Method (Optional) | Belt driven |
| Precision | |
| Spindle Runout | 0.01mm / 0.0003in |
| Resolution | 0.02mm / 0.0004in |
| Laser Module (optional) | |
| Power | 5 Watt |
| Laser Type | 445nm semiconductor diode laser |
| Dust Collection | |
| AeroDust™ Collection System | Integrated spindle & tool cooling with active chip evacuation and dust collection. |
| Supported Materials | |
| Metal | Aluminum, brass, copper and other Non-Ferrous metals. |
| Wood | Hardwoods, softwoods, MDF, plywoods, etc. |
| Plastic | Foam, PVC, ABS, Acrylic, PC, HDPE, etc. |
| Composite material | Carbon fiber, FR4, etc. |
| Laser engrave material | Wood, plastic, fabric, leather, cardboard, etc. |
| Software | |
| Makera Studio — the new Makera CAM. | Makera's first one-click consumer CAM software — available free to all Makera users. |
| Compatible CAD/CAM software: | Fusion360, SolidWorks, AutoCad, VCarve Pro, Aspire, Illustrator, etc. |
| Makera App — the new Makera Controller | Makera's mobile app lets you control and monitor your machine remotely. |
| Makerables | A universal CNC project-sharing platform from Makera. |
| AI Craft | Makera's AI tool lets you Customize CNC Models with Zero Modeling Skills. |
